TEMPEST AL FRAMESET

US$0.00

The Tempest AL is a lightweight aluminium allroad bike built for long days, fast commutes, and weekend escapes. Its adventure-ready geometry offers wide tire clearance, striking the perfect balance between speed and versatility. The T47 bottom bracket adds durability and easy maintenance, while the Seido Banjo carbon fork features internal hub dynamo routing and front rack compatibility for loaded rides and night missions.

"The short chainstays make for spritely handling bike when you need it, but a generous BB drop gives a planted and stable ride on long switchback descents""

SPECIFICATIONS

Model	TEMPEST AL
Color 1	Desert rust
Color 2	-
Frame	6061-T6 double butted aluminium, TA, stealth fender mounts, 68 mm T47 BB shell
Fork	Seido Banjo full carbon, TA, 1.1/2'' - 1.1/8'', 180 mm max rotor size, lowrider rack compatible, internal hub dynamo cable routing
Headset	Sealed integrated headset, 1.1/2'' - 1.1/2''
Through axle	12 x 100 mm / 12 x 142 mm
Seat clamp	Bombtrack Prime 31.8 mm
Rack	-
Weight frameset	1885 g frame (size M, incl. TA, hanger) / 500 g fork (300 mm steerer, incl. TA)
Maximum rider weight	120 kg incl. luggage
ASTM riding condition	1

BUILD INFO

Model	TEMPEST AL
BB standard	T47 - 68 mm shell width
Headset standard (S.H.I.S.)	IS52 / 28.6 \| IS52 / 40
Headset crown race angle	45°
Fork steerer inner diameter	23.6 mm
Fork max tire clearance w/o fender	35-622
Frame max tire clearance w/o fender	35-622
Maximum chainring clearance 1x	44 T with 45 mm chainline
Maximum chainring clearance 2x	50 / 37 T with 45 mm chainline
Seat post diameter	27.2 mm
Seat clamp diameter	30.0 mm
Front derailleur clamp diameter	integrated FD hanger
Frame front derailleur compatible	yes
Brake mount front	FM 160 / 180
Brake mount rear	FM 140 / 160
Frame thickness rear brake mount	20 mm
Maximum rotor clearance front	180 mm
Maximum rotor clearance rear	160 mm
Front through axle	12 mm x 100 mm, 1.5 thread pitch
Rear through axle	12 mm x 142 mm, 1.0 thread pitch
ISO testing standard	Road
Bike trailer	not approved
Seat tube mounted child seat	not approved
Derailleur hanger	Sram UDH
Through axle front	BT-TA-F-601
Through axle rear	BT-TA-R-605

GEOMETRY

FRAME GEOMETRY

Model	TEMPEST
Bike Size	S	M	L
Wheel size	700C	700C	700C
Seat Tube Length	520	550	580
Horizontal TT length	540	557	574
Seat Angle	73.5°	73.5°	73.5°
Head Angle	71.5°	71.5°	71.5°
Headtube Length	145	165	185
BB Drop	72	72	70
Chainstay Length	418	418	418
Fork Offset	53	53	53
Trail	60	60	60
Wheelbase Length	1006	1015	1042
Standover	788	811	836
Reach	375	386	398
Stack	559	578	595
Front Center	598	616	633
Axle to Crown	385	385	385
Minimum rider height *	1600	1700	1790
Maximum rider height *	1710	1810	1900
